QMY6-25 Mobile Concrete Block Machine

QMY6-25 mobile concrete block making machine for various blocks production via changing molds.It can be customized for its electric motors voltage and blocks molds according to your requirement.

Materials: Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.
Application: Widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc.

Leave Message Whatsapp Chat

QMY6-25 Mobile Block Machine is the hydraulic semi automatic mobile brick making machine with lower investment compared with stationary concrete brick machine.

QMY6-25 Mobile Concrete Block Machine

01 Advantage of QMY6-25 movable block machine

Back

1.This is a mobile block machine.
2.This machine can produce any size of hollow blocks and big solid block.
3.No need pallet,will save much cost.
4.One person can operate it.
5.Basic Configuration: QMY6-25 host machine,JS500 Concrete Mixer,Dump truck
6.Other optional Configuration: PLD800 Batching Machine, Cement Silo, Screw conveyor, Loading machine

02 Material Proporation of QMY6-25 brick making machine

Back

a. 8-10% cement, 30-40 % sand , 50-60% crushed stone.
b. 8-10% cement, 30% flyash, 60% sand or stone powder

03 Specifications of QMY6-25 movable block machine

Back

Overall Dimension	180018001500mm
Voltage	adapt to local voltage
vibration force	35.5KN
Cycle Time	10-15 seconds
Motors Power	9.6kw
Weight	2500 kg

04 Production Capacity of QMY6-25 movable block machine

Back

Block type	Image	Size (mm) LWH	Molding cycle	QTY (pcs)/Mould	Qty(pcs)/hour	Qty(pcs)/8hr
Hollow block		400x200x200	25	6	720-1080	5760-8640
Hollow block		400x150x200	25	7	840-1260	6720-10080
